Dustproof IP65 Industrial Touch Panel Embedded Capacitive Touchscreen Panel

Name: Dustproof IP65 Industrial Touch Panel Embedded Capacitive Touchscreen Panel
Brand: LONGYU
Price: 1 USD

Brand Name : LONGYU

Model Number : LYA156K20C

Certification : CE RoHS

Place of Origin : China

MOQ : 1 pcs

Price : TBA

Payment Terms : T/T, Western Union，Paypal

Supply Ability : 10000PCS/Month

Delivery Time : 7-10 Work Days

Packaging Details : 1-5pcs/CTN, Safe, Firm, suitable for international shipping

Luminance : 300 cd/ m²

Touch form : Capactive 10 touch

CPU : RK3568 / Cortex A55 4 core main frequency at 2.0GHZ

IP Grade : Industrial grade IP65 dustproof and water proof

Working Temperature : -10℃ ~ 60℃

Storage temperature : -20℃ ~ 70℃

Size : 15.6 Inch

MIC interface : 1-way MIC interface

Contact Now

Product Description

Capacitive Touchscreen Embedded Industrial Touch Panel 300 cd/ m² PC

LYA156K20C is a high-performance embedded integrated touch screen with the industrial Rockchip RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 15.6-inch LED LCD display (resolution 1920 * 1080) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, HMI, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.

Specifications:

CPU:RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
RAM: DDR 2GB (Selectable 4Gb)
ROM: 32Gb(Selectable 64Gb)
Operating System: Android11.0/Ubuntu18.04/Linux 4.19
GPU: Mali-G52 1-Core-2EE
Luminance:300 cd/ m²(Select a 450cd / m² s)
Material quality:Plastic face frame, metal back cover

Product Performance:

	Performance	Detail
System	CPU processor	RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
	Operating System	Android11.0/Ubuntu18.04/Linux 4.19
	Running memory	2GB/4GB
	EMMC	16GB/32GB/64GB/128GB
	GPU	Mali-G52 1-Core-2EE
Display	Size	15.6 Inch
	Resolving power	1920 * 1080
	Touch form	Capactive 10 touch
	Luminance	300 cd/ m²
	Angle of view	Full perspective
Material	Way to stall	Flat, outer, embedded
	Dimension	383 * 249 * 51mm
	IP protection grade	Industrial grade IP65 dustproof and water proof (operating face)
Power	Power interface	3 PIN*2.54mm terminal DC24V provides power supply
Power	Power input	12-30V Recommended value of 24V
Environmental Characteristics	Working temperature	-10℃ ~ 60℃
	Storage temperature	-20℃ ~ 70℃
	Serial port	2 RS232,2 RS232 / RS485 switch; 6-Road TTL serial port (reuse with serial port)
	Audio interface	1-way MIC interface
	Gigabit Ethernet interface	1 Route 10 / 100 / 1000 Mbps Ethernet port
	HDMI interface	1-Way HDMI output, up to 3840 * 2160 resolution
	TF	1-Route TF card interface
	SIM card	1 Standard drawer-type interface with reserved eSIM interface
	RTC	1 Built-in supercapacitor
	WIFI/BT	2.4G WIFI / BT4.2
	4G interface	The GPS function 4G module should be replaced
	GPIO interface	Expand the miniPCIE 4G module
	GPIO	4-way GPIO, IO direction is input and output configurable, and IO level is 5.0V；
	USB2.0	1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0)
	USB3.0	1 Vertical USB 3.0 (switch through dial switch)
